The DJI Mic Mini Transmitter is small and ultralight, weighing only 10 g, making it comfortable to wear and discreet, with multiple wearing options like magnetic attachment and clip-on.
High-Quality Audio With Stable Transmission
DJI Mic Mini supports omnidirectional audio recording. The receiver can pair with two transmitters simultaneously. High-quality audio can be transmitted stably up to 400 meters.
48-Hour Operation w/ Case
A transmitter and a receiver offer a maximum operating time of 11.5 and 10.5 hours, respectively, and achieve a total of 48 hours of extended use with a fully charged case. Ideal for intensive usage scenarios.
DJI OsmoAudio™ Direct Connection for Premium Sound Quality
The transmitter supports direct connection to select DJI products without a receiver, simplifying your gear and workflow.
Two-Level Active Noise Cancelling
The Basic level is perfect for quiet indoor settings, eliminating noise while preserving vocal clarity. The Strong level excels in noisy environments, significantly cutting ambient noise for clearer vocals.
Automatic Limiting to Prevent Audio Clipping
DJI Mic Mini automatically reduces the volume if the audio input is too high, preventing distortion and ensuring reliable audio quality.
General
Polar Pattern
Omnidirectional
Frequency Response
Low Cut Off: 20 Hz – 20 kHz
Low Cut On: 100 Hz – 20 kHz
Microphone Sensitivity
Microphone Capsule: -40±3 dBV@1 kHz, 94 dB SPL
Signal-to-Noise Ratio (SNR)
70 dB
Max Sound Pressure Level (SPL)
120 dB SPL
Sampling Frequency
48 kHz
Bit Depth
24-bit
Max Input Level (3.5 mm)
Equivalent Noise
24 dBA
Monitor Interface Output Power
Max Transmission Distance
400 m
Transmitter
Dimensions
26.55×26.06×15.96 mm (L×W×H)
Weight
Approx. 10 g (excluding the clip magnet)
Wireless Mode
GFSK 2Mbps
Equivalent Isotropic Radiated Power (EIRP)\ < 20 dBm
Wireless Mode Operating Frequency
2.400-2.4835 GHz
Bluetooth Protocol
Bluetooth 5.3
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP) < 20 dBm
Battery Type Li-ion
Battery Capacity 114 mAh
Battery Energy 0.44 Wh
Battery Voltage 3.87 V
Charging Specification Max 5 V
Charging Temperature 5° to 45° C (41° to 113° F)
Operating Temperature -10° to 45° C (14° to 113° F)
Charging Time 1 hour and 30 minutes
Operating Time 11.5 hours
Internal Recording Available Duration
Receiver
Dimensions
46.50×29.61×19.32 mm (L×W×H)
Weight
Approx. 17.8 g (including the interface cover)
Wireless Mode
GFSK 2Mbps
Equivalent Isotropic Radiated Power (EIRP)
< 20 dBm
Operating Frequency
2.400-2.4835 GHz
Operating Frequency
2.400-2.4835 GHz
Charging Time
2 hours
Charging Cycles for TX and RX
When charging two transmitters and one receiver simultaneously, a fully charged charging case can fully charge them for approx. 3.6 times.
