MacBook M5 Pro 16-inch 1TB|24GB (COMING-SOON)

Finish

• Space Black
• Silver

Chipw

• Apple M5 Pro chip
  • 18-core CPU with 6 super cores and 12 performance cores
  • 20-core GPU
  • Neural Accelerators
  • Hardware-accelerated ray tracing
  • 16-core Neural Engine
  • 307GB/s memory bandwidth
• Media Engine
  • Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
  • Video decode engine
  • Video encode engine
  • ProRes encode and decode engine
  • AV1 decode
• Configurable to:
  • M5 Pro with 18-core CPU and 20-core GPU
  • or M5 Max with 18-core CPU and 32-core GPU (460GB/s memory bandwidth)
  • or M5 Max with 18-core CPU and 40-core GPU (614GB/s memory bandwidth)

Memory

• • 24GB
  • 24GB unified memory
• Configurable to:
  • 36GB (M5 Max with 32-core GPU)
  • or 48GB (M5 Pro or M5 Max with 40-core GPU)
  • or 64GB (M5 Pro with 20-core GPU or M5 Max with 40-core GPU)
  • or 128GB (M5 Max with 40-core GPU)

Storage1

• • 1TB or 2TB
  • 1TB or 2TB SSD
• Configurable to:
  • 2TB or 4TB

Display

• Liquid Retina XDR display
  • 14.2-inch (diagonal) Liquid Retina XDR display;2 3024-by-1964 native resolution at 254 pixels per inch.
• XDR (Extreme Dynamic Range)
  • 1,000,000:1 contrast ratio
  • XDR brightness: 1000 nits sustained full-screen, 1600 nits peak3 (HDR content only)
  • SDR brightness: up to 1000 nits (outdoor)
• Color
  • 1 billion colors
  • Wide color (P3)
  • True Tone technology
• Refresh rates
  • ProMotion technology for adaptive refresh rates up to 120Hz
  • Fixed refresh rates: 47.95Hz, 48.00Hz, 50.00Hz, 59.94Hz, 60.00Hz
• Configurable with:
  • Nano-texture display

Battery and Power

• M5 Pro5
  • Up to 22 hours video streaming
  • Up to 14 hours wireless web
  • 72.4-watt-hour lithium-polymer battery
  • 70W USB-C Power Adapter (included with M5 Pro with 16-core GPU)
  • 96W USB-C Power Adapter (included with M5 Pro with 20-core GPU, configurable with M5 Pro with 16-core GPU)
  • USB-C to MagSafe 3 Cable (2 m)
  • Fast-charge capable with 96W USB-C Power Adapter or higher

Charging and Expansion

• • SDXC card slot
  • HDMI port
  • 3.5 mm headphone jack
  • MagSafe 3 port’
• M5 Pro and M5 Max
  • Three Thunderbolt 5 (USB-C) ports with support for:
  • Charging
  • DisplayPort
  • Thunderbolt 5 (up to 120Gb/s)
  • USB 4 (up to 120Gb/s)

External Display Support

• M5 Pro
• Supports up to three external displays over any combination of Thunderbolt and HDMI ports:
  • Three displays up to a native resolution of 6K at 60Hz or 4K at 144Hz or
  • One display up to a native resolution of 8K at 60Hz or 5K at 120Hz or 4K at 240Hz plus a second display up to a native resolution of 5K at 120Hz or 4K at 200Hz
• Supports up to three external displays over a single Thunderbolt port
• Simultaneously supports the built-in display at full native resolution

Video Playback

• Supported formats include HEVC, H.264, AV1, and ProRes
• HDR with Dolby Vision, HDR10+/HDR10, and HLG

Audio Playback

• Supported formats include AAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus, and Dolby Atmos

Keyboard and Trackpad

• Backlit Magic Keyboard with:
  • 78 (ANSI) or 79 (ISO) keys including 12 full-height function keys
  • Touch ID
  • Ambient light sensor
  • Force Touch trackpad for precise cursor control and pressure-sensing capabilities; enables Force clicks, accelerators, pressure-sensitive drawing, and Multi-Touch gestures

Wireless

• M5 Pro
  • Apple N1 wireless networking chip
  • Wi-Fi 7 (802.11be)6
  • Bluetooth 6
  • Thread networking technology
• Camera
  • 12MP Center Stage camera with support for Desk View
  • 1080p HD video recording
  • Advanced image signal processor with computational video
• Audio
  • High-fidelity six-speaker sound system with force-cancelling woofers
  • Wide stereo sound
  • Support for Spatial Audio when playing music or video with Dolby Atmos on built-in speakers
  • Spatial Audio with dynamic head tracking when using supported models of AirPods, AirPods Pro, and AirPods Max7
  • Studio-quality three-mic array with high signal-to-noise ratio and directional beamforming
  • Voice Isolation and Wide Spectrum microphone modes for enhanced voice clarity in audio and video calls
  • 3.5 mm headphone jack with advanced support for high-impedance headphones
  • HDMI port supports multichannel audio output
• Operating Requirements
  • Line voltage: 100V to 240V AC
  • Frequency: 50Hz to 60Hz
  • Operating temperature: 50° to 95° F (10° to 35° C)
  • Storage temperature: –13° to 113° F (–25° to 45° C)
  • Relative humidity: 0% to 90% noncondensing
  • Operating altitude: tested up to 10,000 feet (3000 meters)
  • Maximum storage altitude: 15,000 feet
  • Maximum shipping altitude: 35,000 feet
• Size and Weight
  • Height: 0.61 inch (1.55 cm)
  • Width: 12.31 inches (31.26 cm)
  • Depth: 8.71 inches (22.12 cm)
  • Weight (M5): 3.4 pounds (1.55 kg)8
  • Weight (M5 Pro): 3.5 pounds (1.60 kg)8
  • Weight (M5 Max): 3.56 pounds (1.62 kg)8

Operating System

• macOS
  • macOS is the world’s most advanced desktop operating system. It includes easy-to-use and powerful features that help you be more productive and creative, Apple Intelligence, and seamless ways to use iPhone with Mac.

Apple Intelligence9

• Apple Intelligence is the personal intelligence system that helps you write, express yourself, and get things done effortlessly. With groundbreaking privacy protections, it gives you peace of mind that no one else can access your data — not even Apple.
