MacBook M5 Pro Max 14-inch 2TB|24GB (COMING-SOON)

Finish

• Space Black
• Silver

Chipw

• Apple M5 Pro Max chip
  • 18-core CPU with 6 super cores and 12 performance cores
  • 32-core GPU
  • Neural Accelerators
  • Hardware-accelerated ray tracing
  • 16-core Neural Engine
  • 460GB/s memory bandwidth
• Media Engine
  • Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
  • Video decode engine
  • Two video encode engines
  • Two ProRes encode and decode engines
  • AV1 decode
• Configurable to:
  • M5 Max with 18-core CPU and 40-core GPU (614GB/s memory bandwidth)

Memory

• 36GB
• 36GB unified memory
• Configurable to:
• 48GB, 64GB, or 128GB (M5 Max with 40-core GPU)

Storage1

• • 2TB
  • 2TB SSD
• Configurable to:
  • 4TB or 8TB

Display

• Liquid Retina XDR display
  • 14.2-inch (diagonal) Liquid Retina XDR display;2 3024-by-1964 native resolution at 254 pixels per inch.
• XDR (Extreme Dynamic Range)
  • 1,000,000:1 contrast ratio
  • XDR brightness: 1000 nits sustained full-screen, 1600 nits peak3 (HDR content only)
  • SDR brightness: up to 1000 nits (outdoor)
• Color
  • 1 billion colors
  • Wide color (P3)
  • True Tone technology
• Refresh rates
  • ProMotion technology for adaptive refresh rates up to 120Hz
  • Fixed refresh rates: 47.95Hz, 48.00Hz, 50.00Hz, 59.94Hz, 60.00Hz
• Configurable with:
  • Nano-texture display

Battery and Power

• M5 Pro Max
  • Up to 20 hours video streaming
  • Up to 13 hours wireless web
  • 72.4-watt-hour lithium-polymer battery
  • 96W USB-C Power Adapter
  • USB-C to MagSafe 3 Cable (2 m)
  • Fast-charge capable with included 96W USB-C Power Adapter or higher

Charging and Expansion

• • SDXC card slot
  • HDMI port
  • 3.5 mm headphone jack
  • MagSafe 3 port’
• M5 Pro and M5 Max
  • Three Thunderbolt 5 (USB-C) ports with support for:
  • Charging
  • DisplayPort
  • Thunderbolt 5 (up to 120Gb/s)
  • USB 4 (up to 120Gb/s)

External Display Support

• M5 Pro Max
• Supports up to four external displays over any combination of Thunderbolt and HDMI ports:
  • Four displays up to a native resolution of 6K at 60Hz or 4K at 144Hz or
  • Two displays up to a native resolution of 8K at 60Hz or 5K at 120Hz or 4K at 240Hz
• Supports up to four external displays over a single Thunderbolt port
• Simultaneously supports the built-in display at full native resolution
• Thunderbolt 5 (USB-C) ports support native DisplayPort 2.1 speeds

Video Playback

• Supported formats include HEVC, H.264, AV1, and ProRes
• HDR with Dolby Vision, HDR10+/HDR10, and HLG

Audio Playback

• Supported formats include AAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus, and Dolby Atmos

Keyboard and Trackpad

• Backlit Magic Keyboard with:
  • 78 (ANSI) or 79 (ISO) keys including 12 full-height function keys
  • Touch ID
  • Ambient light sensor
  • Force Touch trackpad for precise cursor control and pressure-sensing capabilities; enables Force clicks, accelerators, pressure-sensitive drawing, and Multi-Touch gestures

Wireless

• M5 Pro Max
  • Apple N1 wireless networking chip
  • Wi-Fi 7 (802.11be)6
  • Bluetooth 6
  • Thread networking technology
• Camera
  • 12MP Center Stage camera with support for Desk View
  • 1080p HD video recording
  • Advanced image signal processor with computational video
• Audio
  • High-fidelity six-speaker sound system with force-cancelling woofers
  • Wide stereo sound
  • Support for Spatial Audio when playing music or video with Dolby Atmos on built-in speakers
  • Spatial Audio with dynamic head tracking when using supported models of AirPods, AirPods Pro, and AirPods Max7
  • Studio-quality three-mic array with high signal-to-noise ratio and directional beamforming
  • Voice Isolation and Wide Spectrum microphone modes for enhanced voice clarity in audio and video calls
  • 3.5 mm headphone jack with advanced support for high-impedance headphones
  • HDMI port supports multichannel audio output
• Operating Requirements
  • Line voltage: 100V to 240V AC
  • Frequency: 50Hz to 60Hz
  • Operating temperature: 50° to 95° F (10° to 35° C)
  • Storage temperature: –13° to 113° F (–25° to 45° C)
  • Relative humidity: 0% to 90% noncondensing
  • Operating altitude: tested up to 10,000 feet (3000 meters)
  • Maximum storage altitude: 15,000 feet
  • Maximum shipping altitude: 35,000 feet
• Size and Weight
  • Height: 0.61 inch (1.55 cm)
  • Width: 12.31 inches (31.26 cm)
  • Depth: 8.71 inches (22.12 cm)
  • Weight (M5): 3.4 pounds (1.55 kg)8
  • Weight (M5 Pro): 3.5 pounds (1.60 kg)8
  • Weight (M5 Max): 3.56 pounds (1.62 kg)8

Operating System

• macOS
  • macOS is the world’s most advanced desktop operating system. It includes easy-to-use and powerful features that help you be more productive and creative, Apple Intelligence, and seamless ways to use iPhone with Mac.

Apple Intelligence

• Apple Intelligence is the personal intelligence system that helps you write, express yourself, and get things done effortlessly. With groundbreaking privacy protections, it gives you peace of mind that no one else can access your data — not even Apple.
