Description
| Network | |
|---|---|
| Technology | GSM / CDMA / HSPA / EVDO / LTE / 5G |
| 2G bands | GSM 850 / 900 / 1800 / 1900 |
| CDMA 800 / 1900 | |
| 3G bands | HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 |
| HSDPA 850 / 900 / 1900 / 2100 | |
| CDMA2000 1xEV-DO | |
| 4G bands | 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66 – International |
| 5G bands | 1, 2, 3, 5, 7, 8, 12, 20, 25, 26, 28, 38, 40, 41, 66, 75, 77, 78 SA/NSA/Sub6 – International |
| SA/NSA/Sub6/mmWave – USA (Verizon) | |
| Speed | HSPA, LTE (CA), 5G |
| Launch | |
|---|---|
| Announced | 2024, July 10 |
| Status | Coming soon. Exp. release 2024, July 24 |
| Body | |
|---|---|
| Dimensions | Unfolded: 165.1 x 71.9 x 6.9 mm Folded: 85.1 x 71.9 x 14.9 mm |
| Weight | 187 g (6.60 oz) |
| Build | Plastic front (unfolded), glass back (Gorilla Glass Victus 2), aluminum frame |
| SIM | Nano-SIM and multi eSIM |
| IP48 water resistant (up to 1.5m for 30 min) Enhanced armor aluminum frame with tougher drop and scratch resistance (advertised) |
|
| Display | |
|---|---|
| Type | Foldable Dynamic LTPO AMOLED 2X, 120Hz, HDR10+, 2600 nits (peak) |
| Size | 6.7 inches, 101.5 cm2 (~85.5% screen-to-body ratio) |
| Resolution | 1080 x 2640 pixels (~426 ppi density) |
| Cover display: Super AMOLED, 2600 nits (peak), 3.4 inches, 720 x 748 pixels (Gorilla Glass Victus 2), 306 ppi |
|
| Platform | |
|---|---|
| OS | Android 14, One UI 6.1.1 |
| Chipset | Qualcomm SM8650-AB Snapdragon 8 Gen 3 (4 nm) |
| CPU | Octa-core (1×3.3 GHz Cortex-X4 & 3×3.2 GHz Cortex-A720 & 2×3.0 GHz Cortex-A720 & 2×2.3 GHz Cortex-A520) |
| GPU | Adreno 750 |
| Memory | |
|---|---|
| Card slot | No |
| Internal | 256GB 12GB RAM, 512GB 12GB RAM |
| UFS 4.0 | |
| Main Camera | |
|---|---|
| Dual | 50 MP, f/1.8, 23mm (wide), 1.0µm, dual pixel PDAF, OIS 12 MP, f/2.2, 123˚ (ultrawide), 1.12µm |
| Features | LED flash, HDR, panorama |
| Video | 4K@30/60fps, 1080p@60/120/240fps, 720p@960fps, HDR10+ |
| Selfie Camera | |
|---|---|
| Single | 10 MP, f/2.2, 23mm (wide), 1.22µm |
| Features | HDR |
| Video | 4K@30fps |
| Sound | |
|---|---|
| Loudspeaker | Yes, with stereo speakers |
| 3.5mm jack | No |
| 32-bit/384kHz audio | |
| Comms | |
|---|---|
| WLAN | Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, Wi-Fi Direct |
| Bluetooth | 5.3, A2DP, LE |
| Positioning | GPS, GALILEO, GLONASS, BDS, QZSS |
| NFC | Yes |
| Radio | No |
| USB | USB Type-C 3.2, OTG |
| Features | |
|---|---|
| Sensors | Fingerprint (side-mounted), accelerometer, gyro, proximity, compass, barometer |
| Battery | |
|---|---|
| Type | 4000 mAh, non-removable |
| Charging | 25W wired, QC2.0, 50% in 30 min (advertised) 15W wireless 4.5W reverse wireless |
| Misc | |
|---|---|
| Colors | Yellow, Silver Shadow, Mint, Blue, Black, White, Peach |
| Models | SM-F741B, SM-F741B/DS, SM-F741U, SM-F741U1, SM-F741W, SM-F741N |
